STEMPELTÆTNING 66X50X8,3 PTFE+BRONZE PTFE+BRONZE 60 SHORE D/NBR 85 SHORE

STE302-066-050-008 is a rod seal that works as single acting and can be used in piston applications. The material used on this rod seal is made of PTFE+BRONZE.

The dimensions has an inner diameter of 66 mm, an outer diameter of 50 mm and a height of 8.3 mm.

About the sealing profile STE302

STE302 Piston seals are produced from a special compound of bronze-filled PTFE combined with an o-ring that is used as an energizing ring. They work as single acting in the hydraulic cylinders. They can be used safely at high sliding speeds due to the low friction force which is among one of the essential properties of PTFE material. Moreover, they can be used for different type of oils except mineral oils by changing o-ring material.

About the material PTFE+BRONZE

Improves thermal resistance, high pressure stability and extrusion resistance. It is the most preferred filler for hydraulic applications.
